PRINCIPAL DETAILS |
|
|
|
|
|
Length OA |
: 48.00m |
|
Length WL |
: 45.56m |
|
Beam |
: 13.20m |
|
Depth |
: 5.20m |
|
Designed Draft |
: 4.20m |
|
GRT/NRT |
: 1039/311 |
|
Year Built |
: 2007 |
|
Builder |
: Sealink Shipyard, Miri |
|
Classification |
: ABS |
|
Notation |
: Class 1 + Hull, DP-O |
|
It is likely to be DP1 |
|
|
|
|
|
PERFORMANCES |
|
|
Maximum Speed |
:10 knots |
|
Service Speed |
: 8 knots |
|
Type of Fuel |
: Diesel Oil |
|
Range |
: TBA: 20.000 miles |
|
Max. Speed Consumption |
: 8 tons / day |
|
Service Speed Consumption |
: 6,5 tons / day |
|
|
|
|
CARGO CAPACITIES |
|
|
Dead weight |
: 680 t |
|
Deck Cargo |
: 200 t |
|
Deck Strenght |
: 7.5 tons/m² |
|
Clear Deck Area |
: 225 m² |
|
Fuel Oil |
: 639 m³ |
|
Lube Oil |
: 6.26 m³ |
|
Fresh Water |
: 205 m³ |
|
Drill Water/SWB |
: 90 m³ |
|
Foam/Detergent |
: 19 m³ |
|
|
|
|
DISCHARGE RATES |
|
|
Fuel Oil |
: 130m3/hr @ 70m head |
|
Potable Water |
: 90m3/hr @ 75m head |
|
Drill Water |
: 75cum/hr @ 50m head |
|
|
|
|
DISCHARGE RATES |
|
|
Fresh Water Marker |
|
|
Oily Water Separator Sewage |
: 1xGeorim 500 lt/hr @ 2kg/cm³ |
|
Treat Plant |
: 1xII Seung (40 man) |
|
|
|
|
PROPULSION SYSTEM |
|
|
Main Engines |
: 2x2575 BHP @ 1600 rpm Caterpillar |
|
Gearbox |
: For CPP Ratio 7.455:1 |
|
bow thruster |
: 5 mt thruster CPP motor driven |
|
Wheelhouse Control |
: Fwd&aft control |
|
Rudder |
: Independent |
|
Generator |
: 3x360 kW@ 1500 rpm |
|
Emergency Generator |
: 1x45 kW |
|
Propellers An |
: CPP 2650mm dia Berg |
|
Anchors |
: 2xStockless, 1440 kg ea |
|
|
|
|
|
|
|
|
|
|
TOWING/ANCHOR |
|
|
HANDLING/DECK EQUIPMENT |
|
|
|
|
|
Bollard Pull |
: 68 t approx. |
|
Anchor Handling Winch |
: 1x Plimsoll waterfall type 150t |
|
Tow Drum |
: 1000mx56mm |
|
Anchor Handling Drum |
: TBA |
|
Brake Capacity |
: 200t |
|
Capstan |
: 2x 5 t x 0.15 m/min Plimsoll |
|
Tugger Winch |
: 2x 10 t x 0.15 m/min Plimsoll |
|
Steam Roller |
: SWL 150 t 4 m x 1.6 m dia |
|
Anchor Windlass |
: 4.9t @ 11m/min Grade 2 stud line chain |
|
Shark Jaw |
: Hydraulic 300 t, max 114 mm dia |
|
Deck Crane |
: 2 x 6 m |
|
|
|
|
RADIO & NAVIGATION EQUIPMENT |
|
|
SSB |
: Furuno – FS 1520. |
|
VHF |
: Furuno – FM 8 8005 |
|
Radar |
: 1 x IMO approved (Furuno) |
|
Echo Sounder |
: JMC – F 3000 W |
|
Speed Log |
: IMO Type -Anthea |
|
Gyro Compass |
: 1 x Simrad with Autopilot |
|
GPS |
: 2xFuruno |
|
GMDSS |
: 1xFurumo |
|
Magnetic Compass |
: 1xDaiko Keiki |
|
Navtex Receiver |
: 1xHanshin |
|
SART |
: 2xACR Parthfinder |
|
Portable VHF Radio |
: 1xJMC |
|
Inmarsat |
:1xFuruno c/w SSAS capability |
|
EPIRB |
|
|
AIS |
:1xFuruno – FA -150 |
|
|
|
|
FIRE FIGHTING EQUIPMENT |
|
|
Fire Pump |
: 2xseawater @ 1500m³/hr @ 14 bar |
|
Fire Monitor |
:2xhandwheels, 1200 m³/hr |
|
Foam Tank |
: 19.33 m³ |
|
Dispersant System |
: 19.33 m³ |
|
Full Flooding |
: CO2 System Engine Room |
|
|
|
|
LIFE-SAVING EQUIPMENT |
|
|
Search Lights |
: 2x1000w |
|
Floodlights |
: 6x500w |
|
Liferafts |
: 4x20-men Fujikura |
|
Lifebuoys |
: 8xSelf igniting elect lights |
|
Lifejackets |
: 46 pcs |
|
Rescue Boat |
: 1xVailant c/w 25 BHP Solas Approved |
|
|
|
|
ACCOMMODATION |
|
|
Total |
:40 person |
